The FiberGuide® system is a complete set of products designed and manufactures to ensure total off-frame protection. Basic components include horizontal and vertical straight sections, horizontal and vertical elbows, downspouts, junctions and numerous support hardware and flex tube kits. The FiberGuide system is available in a variety of sizes: • 2x2 - Ideal for smaller installations or vertical routing of a maximum of 400 2mm patch cords. All 2x2 FiberGuide products are shipped with cover. • 2x6 - Designed for height-restricted environments. It features a maximum capacity of 1,200 2mm patch cords. • 4x4 - Features a maximum trough capacity to support 1,600 2mm patch cords. • 4x6 - Features a maximum trough capacity to support 2,400 2mm patch cords. • 4x12 - Features a maximum trough capacity to support 5,000 2mm patch cords. • 4x24 - Features a maximum trough capacity to support 10,000 2mm patch cords

Speed of Installation: CommScope’s FiberGuide system features a variety of products that enable quick installation. An Express Exit™ drop saves up to 40 minutes of installation time per drop. Speed of Deployment: Patented Express Exit™ drop enables fiber deployment in seconds. Raceway Flexibility: FiberGuide system features 38 support structures, over 75 fittings, one dozen drop options and several other components to suit any application. Fiber Protection: 2-inch (5cm) minimum bend radius is maintained throughout the system regardless of the raceway size. Unique channel design that allows the systems to be attached to support structures without cutting or drilling any holes, ensuring that patch cords do not come in contact with screw heads or bolts. Strength and Durability: Straight sections engineered to be selfsupporting over a span of up to 6-feet. 100% raceway
